WINCH M

Winch M is our standard for a wide range of setups. You can control individual fixtures or connect larger fixtures to multiple winches. They can transmit anything from a simple DMX dimming signal to control of individual pixels and even video.

WINCH M MONO

The Winch M is our most trusted and proven solution. Now in its 5th generation, the Winch M represents extensive experience and innovation and has been in continuous use for many years with proven, reliable functionality.

The Winch M is our most trusted and proven solution. Now in its 5th generation, the Winch M represents extensive experience and innovation and has been in continuous use for many years with proven, reliable functionality.
The Winch M Mono is specifically designed for mono LED fixtures and allows RGBW lights to be controlled via KLC/DMX dimming.

The Winch M Mono is specifically designed for mono LED fixtures and allows RGBW lights to be controlled via KLC/DMX dimming. Like all our winches, it offers full real-time control from any lighting console or third-party control software. A simplified DMX mapping table makes programming and control easy. The reinforced lift cable is fully retractable and has a special quick-lock connector at the end.


All our Winch M products are fully CE, UL and DGUV17 / BGV C1 compliant.

RELATED PROJECTS

SPECIFICATION

Safe working load

1.1-6.6 lb | 0.5-3 kg

Lifting height / stroke

23 ft | 7 m

Lifting speed

0-2.3 ft/s | 0-0.7 m/sec

Positioning accuracy

+/- 0.04 in | 1 mm

Input voltage range

100-240 V AC, 50-60 Hz

Power consumption

300 W at 230 V, 50 Hz

Power output to light fixture

4 channels 0-27.5 V DC, max. 1 A per channel, total max. 4 A

Power connection

PowerCON TRUE1 TOP (In & Thru)

Data connection

5-pin XLR (In & Thru up to 24 units)

Protocol

KLC, DMX

Operating temperature

32-104 °F | 0-40 °C

Storage / shipping temperature

5-122 °F | -15-50 °C

Relative humidity

max. 55%, non-condensing

Mount

To 16 mm Manfrotto TV Spigot

Dimensions (without clamp)

11 x 11 x 19 in | 280 x 280 x 485 mm

Weight

15 lb | 6.8 kg

Interchangeable Fixtures

RGB(W) dimming

Approval

CE, UL & DGUV17 / BGV C1 compliant

WINCH M PIXEL

The Winch M Pixel offers the same functionality as our Winch M Mono and uses the same proven hardware.

The Winch M Pixel offers the same functionality as our Winch M Mono and uses the same proven hardware.
The Winch M Pixel allows individual LED pixel control, which makes it possible to control complex individual or connected lighting fixtures such as String, Ring or Rod Triangle.

In addition, the Winch M Pixel allows individual LED pixel control, which makes it possible to control complex individual or connected lighting fixtures such as String, Ring or Rod Triangle. With individual pixel control of all connected LEDs, more complex light animations are possible and easy to create.

The data for each pixel element is sent via KLC/Art-Net, while the winch itself can also be controlled via KLC/DMX. The Winch M Pixel also allows CAN-based LED control with an alternative configuration.

RELATED PROJECTS

SPECIFICATION

Safe working load

1.1-6.6 lb | 0.5-3 kg

Lifting height / stroke

23 ft | 7 m

Lifting speed

0-2.3 ft/s | 0-0.7 m/sec

Positioning accuracy

+/- 0.04 in | 1 mm

Input voltage range

100-240 V AC, 50-60 Hz

Power consumption

300 W at 230 V, 50 Hz

Power output to light fixture

max. 4 A

Power connection

PowerCON TRUE1 TOP (In & Thru)

Data connection

EtherCON (In)

Protocol

KLC, DMX, Art-Net

Operating temperature

32-104 °F | 0-40 °C

Storage / shipping temperature

5-122 °F | -15-50 °C

Relative humidity

max. 55%, non-condensing

Mount

To 16 mm Manfrotto TV Spigot

Dimensions (without clamp)

11 x 11 x 19 in | 280 x 280 x 485 mm

Weight

15 lb | 6.8 kg

Interchangeable Fixtures

RGB(W) dimming or pixel mappable

Approval

CE, UL & DGUV17 / BGV C1 compliant

WINCH M DATA

The Winch M Data offers all the functionality of our other Winch M products and uses the same proven hardware.

The Winch M Data offers all the functionality of our other Winch M products and uses the same proven hardware.
The Winch M Data is capable of delivering a video signal to any connected element or fixture via an EtherCon connection.

In addition, the Winch M Data is capable of delivering a video signal to any connected element or fixture via an EtherCon connection. This allows individual video content to be displayed on the connected fixtures. The video data is transmitted completely independently of KLC/DMX or KLC/ Art-Net control. Complex video LED panel objects can be moved and tilted independently while video data is continuously streamed.

Our latest product for which we recommend the use of Winch M Data is our Video Triangle.
